5818/5828:
Technical Datasheet:
| Range of measurement | Sensitivity and the voltage drops | Accuracy | Error tables example method | |
| DC Current | 0-100uA-2.25mA-25mA-500mA | 0.5V | ±3% | With an indicative value Percentage Calculatioin |
| DC Voltage | 0-0.5V-2.5V-10V-50V | 10kΩ/V | ±3% | |
| 250V-1000V | 4.5kΩ/V | |||
| AC Voltage | 0-10V-50V-250V-1000V | ±5% | ||
| DC Resistor | R×1 R×10 R×100 R×1k R×100k | Central Value 20 | ±10% | |
| Turn off the buzzing | R×3(reference value) Below 30Ω buzzer sounds | |||
| Capacitance | C×0.1 C×10 C×100 C×1k C×10k | |||
| LI Detection(mA) | R×1 | R×10 | R×100 | R×1k |
| 150mA | 15mA | 1.5mA | 150UA | |
| LV Detection(V) | R×1-R×1k | 0-3V | ||
| Transistor DC Magnification hFE | R×10hFE shift zero | 0-1000 | ||
| Infrared remote control Launch detection | Vertical angle ±15° Distance 1-30cm | Red LED indicator(blinking) | ||
| Battery Power | 1.2V-1.5V-2V-3V-3.6V RL=12Ω | |||
| Audio level dB | -10dB~+22dB | 0dB=1mW/600Ω | ||
